Ajax Hub BP Jeweller | Battery-Powered Panel | Off-Grid & Vacant Properties
Summary
The Hub BP Jeweller is a wireless battery-powered control panel designed to provide uninterrupted security for facilities without permanent electricity access. Ideal for vacant properties, remote sites, and locations with unreliable power supply, this robust hub delivers continuous monitoring powered by external batteries.
Supporting photo verification through MotionCam detectors, the Hub BP Jeweller connects to the Ajax Cloud server via dual SIM cards across 2G/3G/LTE networks, ensuring reliable communication with automatic failover between network operators. The hub features external antenna connectors for cellular, Jeweller, and Wings communication channels, enabling optimal signal strength even in challenging installation environments.
Operating on the secure OS Malevich platform, the hub controls up to 100 wireless Ajax devices using encrypted Jeweller and Wings radio protocols. The system provides communication ranges of up to 2,000 meters in open space, with instant alarm notifications delivered in under one second. With support for 32 automation scenarios, 9 security groups, and 50 users, Hub BP Jeweller offers comprehensive protection and flexible control for residential and commercial applications.
Features
- Supports up to 100 wireless Ajax devices with Jeweller and Wings encrypted protocols
- Dual SIM card slots with automatic failover between network operators
- Photo verification support for MotionCam and MotionCam Outdoor detectors
- Extended battery operation: up to 23 months with internal battery (7.2V/95Ah) in standard mode
- Advanced Battery power saver mode extends operation up to 46 months
- External antenna connectors for cellular, Jeweller, and Wings communication channels
- Communication range up to 2,000 m (6,550 ft) in open space
- Instant alarm notifications in less than one second
- 32 automation scenarios for comprehensive facility management
- 9 security groups with 50 user accounts and 50 rooms
- Dual tamper buttons for enhanced physical security
- OS Malevich operating system with over-the-air updates
- British disco LED indication mode for visual system status
- Jamming detection with automatic frequency switching
- Connection to monitoring company’s central monitoring station
- Compatible with Ajax cameras, NVRs, and third-party RTSP/SDK cameras
- Supports up to 492 standalone Ajax cameras
- Configurable server polling intervals from 60 seconds to 6 hours
- Operating temperature range: -10°C to +40°C (14°F to 104°F)
- Grade 2 certification (EN 50131, PD 6662:2017, NIST AES-128)
- Available in white and black color options
- Dimensions: 196 × 238 × 100 mm (7.72″ × 9.37″ × 3.94″)
- IP40 protection rating
FAQs
What is the maximum number of devices that can be connected to Hub BP Jeweller?
Hub BP Jeweller supports up to 100 wireless Ajax devices, allowing comprehensive coverage for both residential and commercial properties.
How long does the hub operate on battery power?
With an internal non-rechargeable battery (7.2V/95Ah), the hub operates for approximately 23 months in standard mode. In Battery power saver mode, operation extends to 46 months. External zinc-air batteries can provide even longer operation times, with some models lasting up to 69 months.
Does Hub BP Jeweller support photo verification?
Yes, the hub supports photo verification through MotionCam and MotionCam Outdoor detectors. When triggered, these detectors capture a series of images transmitted via the Wings protocol, with the first photo delivered in 9 seconds.
What happens if one SIM card loses connection?
Hub BP Jeweller features dual SIM card slots with automatic failover. If one network operator becomes unavailable, the hub automatically switches to the other SIM card and notifies users and the monitoring station of the change.
Can I use external antennas with this hub?
Yes, Hub BP Jeweller includes SMA female connectors for external antennas on all three communication channels: cellular (LTE), Jeweller, and Wings. This is particularly useful for installations in areas with weak signal strength or where the hub is located inside metal structures.
What is the Battery power saver mode?
Battery power saver mode is an advanced feature that extends battery life by adjusting polling intervals and disabling certain functions. Device polling occurs every 5 minutes, server polling every 6 hours, and LED backlight is disabled, significantly reducing power consumption.
How is the hub protected against jamming attempts?
When a jamming attempt is detected, the system automatically switches to an idle radio frequency and sends notifications to both the monitoring station and system users, ensuring security is maintained even during interference attempts.
Can Hub BP Jeweller connect to video surveillance systems?
Yes, the hub is compatible with Ajax cameras and NVRs, as well as third-party cameras supporting RTSP protocol or SDK integration. It can support up to 492 standalone Ajax cameras or up to 224 cameras via Ajax NVRs.
What certifications does Hub BP Jeweller hold?
Hub BP Jeweller is certified to Grade 2 standards including EN 50131, PD 6662:2017, and NIST (AES-128), making it suitable for professional security installations and insurance-grade requirements.
How do I reset the hub to factory settings?
To reset Hub BP Jeweller: turn on the hub, remove all users and installers, hold the power button for 30 seconds until the LED indicator starts blinking red, then remove the hub from your account.
What types of batteries are recommended for Hub BP Jeweller?
Ajax recommends zinc-air alkaline batteries for extended battery life. Before connecting, remove the stickers or open the air shutoff valves and leave the battery with access to air for 2 hours. Popular models include Cegasa eZ8 12/600 (18 months standard / 69 months power saver) and Masterbattery MC-ZA1200-7.5 (19 months standard / 42 months power saver).
Specifications
- Wireless Communication Protocol: Jeweller (868.0–868.6 MHz, 905.0–926.5 MHz, 921.0–922.0 MHz)
- Photo Transmission Protocol: Wings (868.7–869.2 MHz, 915.85–926.5 MHz)
- Cellular Network Support: 2G/3G/LTE (dual SIM cards, micro SIM)
- Maximum Connected Devices: 100 wireless Ajax devices
- Maximum Ajax Cameras: Up to 492 standalone
- Maximum Users: 50
- Maximum Rooms: 50
- Automation Scenarios: 32
- Security Groups: 9
- Communication Range: Up to 2,000 m (6,550 ft) in open space
- Alarm Notification Speed: Less than 1 second
- Operating System: OS Malevich with over-the-air updates
- Internal Power Supply: 4.2–16.2 V⎓ rechargeable and non-rechargeable batteries up to 195 Ah (not included)
- External Power Supply: 6–12 V⎓ or 4.2–16 V⎓ zinc-air battery up to 600 Ah (not included)
- Battery Life (Internal NB 7.2V/95Ah): 23 months standard mode, 46 months power saver mode
- Battery Life (External Cegasa eZ8 12/600): 18 months standard mode, 69 months power saver mode
- Operating Temperature Range: -10°C to +40°C (14°F to 104°F)
- Operating Humidity: Up to 75%
- Dimensions: 196 × 238 × 100 mm (7.72″ × 9.37″ × 3.94″)
- Weight: 1,010 g (35.63 oz)
- Protection Rating: IP40
- Tamper Protection: Dual tamper buttons
- External Antenna Connectors: SMA female (cellular, Jeweller, Wings)
- LED Indication Modes: Hub-server connection, British disco
- Certification Standards: EN 50131 (Grade 2), PD 6662:2017, NIST (AES-128)
- Available Colors: White, black
- Complete Set: Hub BP Jeweller, installation kit, quick start guide
- Warranty Period: 2 years
