CAST Voice Sounder Base
£34.63 (inc VAT: £41.56)
Summary
The C-TEC CA454A/W is a base voice sounder designed to deliver superb sound intelligibility in fire alarm systems. This device features multiple selectable messages and tones, ensuring clear communication during emergencies. With its robust construction and advanced capabilities, the CA454A/W is an ideal choice for enhancing safety in various environments.
Utilising the innovative CAST protocol, this sounder allows for seamless integration with multiple devices, improving the overall efficiency and responsiveness of fire alarm systems.
Features
- Six selectable messages with tones (2 evacuate, 1 alert, 1 all clear & 2 system test messages)
- 15.5mA typical alarm current
- Group addressing facility for simultaneous operation of multiple devices
- Optional BF330CTLIDW white or BF330CTLIDR red cap available for stand-alone use
- IP21C rated for indoor use
- Custom messages and CAST Lockdown Sounders available to special order
Specifications
- Protocol/compatibility : Compatible with C-TEC’s CAST protocol Addressable Fire Panels
- Application/operation : Designed to be ceiling mounted – either stand-alone with a red or white cap or as part of a stacked Voice
Sounder/Detector Base combination - Supply/operating voltage: 24 to 40V DC.
- Quiescent current : 470µA typical
- Nominal SPL (Sound Pressure Level) : 89 dB(A) @ 1 m
- Alarm current : 15.5mA @ 24 to 40V DC
- Indicators : Polling (red LED)
- Product dimensions (mm) : 122mm diameter x 46mm deep (not including optional CAST detector and base)
- IP Rating : IP21C (Type A)
- Weight : 160g
- Operating conditions/temperature: -10ºC to +55ºC. Max. 95% RH (Non-condensing)
- Notes: Includes the same electronics as our CAST EN54-3, 13 & 17 certified Base Sounder
Downloads
- Datasheet (Adobe PDF)
