SMS SenTRI Beam Detector Angle Bracket with Base
£127.86 (inc VAT: £153.43)
Summary
The SMS SEN-741-01 Beam Detector Angle Bracket with Base provides a versatile mounting solution for the SENTRI-BEAM beam detector in challenging installation environments. This professional-grade mounting accessory is specifically engineered for applications where conventional vertical surface mounting is not practical or where the beam path requires non-perpendicular alignment to the installation surface.
As part of Gent’s comprehensive S-Quad beam detection system, this angle bracket delivers exceptional flexibility for fire detection installations in large open spaces, warehouses, and industrial facilities. The bracket comes complete with a pre-installed S-Quad base, ensuring seamless integration with Gent’s advanced analogue addressable fire alarm systems whilst maintaining full EN54 compliance for professional fire safety installations.
Features
- Multi-angle fitting capability for complex installations
- Simple alignment system for reduced installation time
- Robust construction suitable for industrial environments
- Compatible with S4-34740 beam detector systems
- Pre-installed S-Quad base eliminates separate base purchase
- Wide angle adjustment range accommodates difficult mounting scenarios
- Professional-grade mounting hardware included
- Supports loop-powered beam technology
- Designed for use with Vigilon and Nano control panels
- Facilitates optimal beam path alignment in challenging spaces
FAQs
What is the maximum angle adjustment range?
The SEN-741-01 provides wide angle adjustment up to ±30 degrees, offering exceptional flexibility for non-standard installations where the beam path cannot be perpendicular to the mounting surface.
Is the detector base included with the bracket?
Yes, the angle bracket comes supplied with a pre-installed S-Quad base, eliminating the need for separate base procurement and ensuring complete compatibility with Gent beam detectors.
Which beam detectors is this bracket compatible with?
The SEN-741-01 is specifically designed for use with the Gent S4-34740 beam detector system and is compatible with the full range of Vigilon and Nano control panels.
What certifications does this mounting bracket meet?
The bracket is designed to maintain EN54 parts 12 and 17 certification when used with compatible Gent beam detection systems, ensuring compliance with European fire detection standards.
Can this bracket be used for ceiling mounting applications?
The SEN-741-01 is specifically designed for applications where vertical surface mounting is not suitable. For standard vertical surface mounting, the SEN-741-03 parallel bracket would be more appropriate.
What type of detector base is pre-installed?
The bracket comes with a pre-installed SEN-700 base, which is compatible with SMS’s advanced analogue addressable detection technology and supports loop-powered operation.
Specifications
- Part Number: SEN-741-01
- Product Type: Beam Detector Angle Bracket with Base
- Manufacturer: SMS
- Angle Adjustment Range: ±30 degrees
- Compatible Detector: SENTRI-BEAM Beam Detector
- Base Type: Pre-installed SenTRI Base
- Certification Compliance: EN54 Parts 12 and 17
- Panel Compatibility: Vigilon and Nano Control Panels
- Installation Type: Multi-angle Applications
- Power Type: Loop Powered Technology
- Application: Non-vertical Surface Mounting
- Detection Technology: Linear Beam Detection
- System Type: Analogue Addressable
- Mounting Hardware: Included
- Operating Environment: Indoor Fire Detection Applications
Downloads
- Brochure (Adobe PDF)
Additional information
| Weight | 1.00 kg |
|---|
