EvacGo Single Relay Output Module with Built-in Isolator
£65.84 (inc VAT: £79.01)
Summary
The 20-VMMC120-ADV Single Relay Output Module is a loop-powered device designed with a fully digital protocol to provide form C changeover contacts. This module is ideal for controlling equipment for DDA compliance, such as vibrating pillows, ensuring accessibility and safety.
The output channel of the module is a normally de-energised relay that is activated by a command from the control panel. It offers a fast and secure response, incorporating a bidirectional short circuit isolator for enhanced reliability.
Connections are facilitated through plug-in terminal blocks that accommodate conductors up to 2.5 mm², allowing for easy installation. The module can be conveniently mounted within an electrical box or enclosure.
Features
- Short circuit isolators in each device to the requirements of EN54-17
- Auto addressing capability by the control panel or manually using a hand held programmer
- Digital checking of double address
- Line quality information
- Bicolour (red/green) LED driven by the control panel
Specifications
- Power Supply : 15-40 Vdc
- Maximum Current Consumption : 6 mA
- Operating Temperature Range : -30°C to +70°C
- Humidity (Non Condensing) : 85% RH
- Relay Switching : 2A / 30 Vdc
- Dimensions H x W x D : 52 x 75 x 28 mm
- Weight : 180 g
- IP Rating : 21C
Downloads
- Datasheet (Adobe PDF)
Additional information
| Weight | 1 kg |
|---|---|
| Device Type |
