Lexicomm AssistCall Over Door Plate in Stainless Steel

FAQ

How does the over door indicator operate when an alarm is activated?

When the alarm is activated, the over door indicator will flash blue and play an alarm tone. Once the alarm is acknowledged by pressing a cancel button, the indication changes to solid blue and the sounder emits a pair of beeps every 15 seconds to confirm help is on the way.

Where should the over door indicator be mounted?

The over door indicator should be mounted above the door on the corridor side in accordance with Building Regulations Document M (Access for the Disabled) and BS 8300-2:2018 requirements. This ensures maximum visibility for staff and emergency responders.

What cable types are compatible with the ViAC-ODP-SS?

The unit supports standard two core cable wiring including PVC or fire rated 2 core 1mm cable up to 500m distance, or Cat5/6 cable with 1 pair 0.22mm up to 50m distance. Fire rated cable is required if connected to a Refuge Point.

Can multiple over door indicators be wired together?

Yes, multiple units can be wired in any order using standard two core cable. Each plate has two sets of two part terminals allowing simple daisy-chain connections. Refer to the AssistCall Installation Notes document for information about the maximum number of devices per line.

Is the device suitable for surface mounting?

Yes, the ViAC-ODP-SS supports both flush and surface mounting options to accommodate different installation requirements and building types.

What systems is the over door indicator compatible with?

The ViAC-ODP-SS is fully compatible with the Lexicomm EVC range of equipment and the standalone AssistCall range, providing flexible integration options for different emergency communication system configurations.
